Roland VersaSTUDIO BN-20D Desktop Direct-to-Film System Textile Printers, A Better Direct-to-Film Solution Superior Output
34% off
Roland VersaSTUDIO BN-20D Desktop Direct-to-Film System Textile Printers, A Better Direct-to-Film Solution Superior Output is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
We deliver Canada-wide or visit us at our showroom location at 1300 Alness St. Unit 1A, Concord, Ontario
Description
Description
Roland VersaSTUDIO BN-20D Desktop Direct-to-Film System Textile Printers, A Better Direct-to-Film Solution Superior Output
Flexible Open Financing options are available.
Get pre-qualified in seconds - Start now!
Leasing Options Available – Apply Here
DESCRIPTION:
The Roland BN-20D takes customizing clothing to the next level without the hefty price tag!
You can create stunning full-color designs and graphics easily. This new system is made to handle even the most detailed and intricate artwork. Let your creativity soar while you create beautiful on-demand prints.
With the VersaSTUDIO BN-20D, you get all the features and reliability of Roland DG’s best-selling BN-20, as well as the advantages of an integrated direct-to-film printing solution. Enhancing apparel with detailed, eye-catching graphics, images and text is a simple, trouble-free process with a BN-20D:
- A simple printing process - transfer detailed graphics and fine text quickly and easily without weeding or masking.
- A complete solution - all the features of the BN-20D printer plus direct-to-film inks, transfer powders, and films (sold separately).
- More than a printer - the BN-20D can also be used as a stand-alone vinyl cutter.
- VersaWorks 6 RIP software included - Roland DG's most powerful, intuitive RIP to date.
Roland BN-20D Specifications
With a maximum print resolution of up to 1,440 dpi, the BN20-D provides superior image quality and detail.
Because it’s a DTF film transfer printer, you can avoid the difficult and time consuming process of weeding and masking. You will be able to print artwork with fine lines and small details unlike when working with traditional vinyl.
Additionally, it can also be used as a stand-alone vinyl cutter if needed.
How does the Roland BN-20D printer work?
Made to use with unique powder, film, and inks, the BN-20D streamlines the process of transferring graphics and text designs to blanks and apparel in a way that achieves optimal results.
The Roland BN-20D system has a maximum print width of 20 inches, eliminating the need to feed the printer sheet after sheet. You can simply load the media, send your artwork to the printer, and walk away!
This allows harried business owners the time to work on other important tasks around their shop or even complete the dtf process on transfers from a previous job.
Advantages of the Roland BN-20D Direct-to-Film System
- DTF Capabilities – You will be able to transfer the most detailed and intricate graphics and fine text quickly and easily without having to weed or apply a transfer mask.
- Versatility – Great for multi-use, this machine can create film transfers prints but can also serve as a stand-alone vinyl cutter. It also accommodates various rolls of media outside of the Roland brand.
- Maintenance – The BN-20D requires little maintenance and can create consistent prints without having to “babysit” the machine.
- VersaWorks 6 RIP Software – Included with the Roland BN-20D machine, this is the most powerful and intuitive software on the market.
- White Ink Regulation System – The dedicated channels for CMYK and improved white ink delivery system, help produce rich and vivid color while achieving optimal white ink opacity for light and dark colored garments.
Does It Come with Printing Software?
Absolutely, you’re going to want to make sure you’re in control of how your artwork looks! Included with this dtf film transfer printer comes VersaWorks 6 RIP software.
Engineered to make the printing process easy for users of all skill levels, this software features RIP production tools for managing all your print-and-cut output.
- HARLEQUIN RIP dual core engine and 64-bit native processing for enhanced speed and file handling.
- Add cut lines directly in the RIP— change vector data into cut line data.
- A variety of profiles designed for different types of application, enable high-quality print output without difficult settings.
- Easy drag-and-drop interface allows you to quickly add jobs to the print queue.
- Integrated spot color libraries include Pantone and Roland DG Color libraries.
- Intuitive tiling, cropping, nesting and other features that have made VersaWorks the world’s favorite software RIP.
What can you Print with the Roland BN-20D?
Because this is a multi-purpose system that can be used for dtf transfer printing and as a vinyl cutter alone, the BN-20D can customize tons of light and dark colored substrates.
Here are just some customization ideas to get you started:
- T-shirts
- Tote Bags
- Sweatshirts
- Aprons
- Backpacks
- Hats
- Polos
- Button Downs
- And Much More!
Comparison of the Roland BN-20/A (A version) and the Roland BN-20D
The Roland BN-20/A and Roland BN-20D have some similarities, the biggest and most obvious being the appearance of the machines. Although the list of similarities is quite short, we’ll discuss them briefly.
- Types of Ink
Both the BN-20 (not the BN-20A) and the BN-20D can print white ink. For the Roland BN-20D, this is used as a base on top of the full color image, producing an opaque transfer. Once the curing dtf powder is applied to the transfer, then it forms an adhesive that’s ready to be applied to your garment.
- Print Size
Another similarity between these machines is that they all can accommodate media rolls up to 20 inches wide, so it’s easy to load.
This gives you the ability to print tons of small images, designs, or logos all at once!
Differences Between the Roland BN-20/A and the Roland BN-20D
With similarities, come differences as well. Between ink colors, materials, and printing process, these machines differ greatly.
- Materials and Ink
For example, the Roland BN-20/A uses eco-solvent ink while the Roland BN-20D uses specialty inkjet ink in CMYK and white.
For the BN-20D, specialty ink, transfer film, and powder are needed in order to print dtf transfers. Otherwise, this system can be used solely as a vinyl cutter.
This means that while the Roland BN-20/A can print on vinyl, sticker paper, wall cling, canvas material and much more, the BN-20D cannot.
- Image and Graphic Set Up
When prepping artwork for the BN-20/A, contour cut lines are required for the machine to be able to make cuts after the artwork is printed.
This typically takes place in a separate software like Adobe Photoshop.
Unlike the BN-20/A, the BN-20D dtf printer doesn’t need cut lines because it doesn’t cut. However, it will require different steps in the software to start printing.
- Printing Process
When printing and cutting with the Roland BN-20/A, the art is printed first then fed back through for the cutting to take place. Once that process is done, the transfer is ready for application.
On the other hand, the BN-20D requires a few more steps. First, the color layer is printed. In a second pass, a white top layer will be printed on the image.
This dtf transfer is now ready for the powder to be applied. After the dtf powder is added to the transfer, it will need to melt under a heat press for the adhesive to bond. Lastly, it can be heat applied to a garment to create a wonderful customized product.
Because of the differences in the printing processes, Roland BN-20D transfers skip the weeding and masking process while BN-20/A transfers can’t.
Depending on your business’ needs, this will help you determine which machine is right for you.
A Complete Direct-To-Film Solution You Can Rely On
A Better Direct-to-Film Solution Superior Output
- The BN-20D offers simple operation, outstanding print quality, and renowned Roland DG reliability. A complete DTF solution including S-PG inks, S-F164 film, and S-POWDER (each sold separately).
- Provides a simple process for customising apparel and accessories with eye-catching graphics – including detailed images and text – without weeding or masking.
- Dependable, consistent performance and low maintenance requirements minimise downtime and optimise productivity. Comes with world-class Roland DG service/support and a One-Year TroubleFree Warranty.
Performance Features
- Ink delivery and recirculation advancements for increased reliability, vivid colour, and greater white opacity for printing on light- and dark-coloured garments.
- Variable dot control produces droplets of seven different sizes for superior detail, photographic reproduction, gradations, and contrast.
- Included Roland VersaWorks 6 RIP software boasts a HARLEQUIN RIP dual core engine, intuitive drag-and-drop functionality, efficient processing of complex PDF, EPS and PS files, Roland Colour System and PANTONE libraries, and other useful tools and features.
Superior Output
- The BN-20D Direct-to-Film solution lets you print detailed images and fine lines that would be extremely difficult to weed using vinyl. Transferring even complex
designs/images and intricate text is quick and easy. - With the garment colour acting as the background of the design, it gives a soft, natural feel to the transfer.
- Transferable onto light and dark fabrics, including cotton, polyester, and blends, denim, nylon, rayon and more to produce a wide variety of garments.
Additional Features
+ S-F164 Film is available in 20-inch rolls to maximise productivity. The BN-20D can also accommodate various roll sizes from third-party manufacturers (ranging from
as small as 150 mm up to 515 mm), giving customers the flexibility to use the solution that works best for their specific business needs.
+ With the BN-20D, making the switch from direct transfer printing to CAD-cut vinyl cutting requires just a few clicks of the mouse in VersaWorks 6. There’s even a “Job Assistant” function that can be used as an added convenience feature for creating contour cut lines directly in the RIP when a PDF file is being used.
Technical Specs
|
|
BN-20D |
|
|
Printing method |
Piezoelectric inkjet / Grit roller feed |
|
|
Acceptable media |
Width/thickness |
150 mm to 515 mm / Maximum 0.4 mm with liner and 0. 22 mm without line |
|
Media roll weight |
Max. weight 6 kg |
|
|
Roll/core diameter |
Max. outer diameter 150 mm / Core diameter: 50.8 mm or 76. 2 mm |
|
|
Ink |
Ink technology |
Pigment |
|
Capacity |
220 ml cartridge |
|
|
Colors |
5 Color – CMYK+Wh (Cyan, Magenta, Yellow, Black, White) |
|
|
Cutting speed/blade force |
10 mm/s to 150 mm/s / 30 to 300gf |
|
|
Connectivity |
USB 2.0 |
|
|
Printing resolution |
Maximum 1440 dpi |
|
|
Power-saving function |
Automatic sleep feature |
|
|
Power supply |
AC 100 to 240±10 %, 1.0 A, 50/60 Hz |
|
|
Printer dimensions |
1009 W x 582 D x 293 H mm / 36 kg |
|
|
Included items |
Power cable, USB cable, blade, blade holder, User’s Manual, etc. |
|
|
Maintenance |
Cap top |
User replaceable |
|
Cap top replacement sequence |
Start from utility |
|
|
Wiper |
User replaceable |
|
|
Felt wiper |
User replaceable |
|
|
Manual cleaning |
Every day after the end of the working day |
|
|
Consumables (DTF) |
Film |
S-F164 film |
|
Powder |
S-Powder |
|
|
Cleaning liquid |
CJ-CL |
|
